JW1050 Waterproof Wire Nut for 22–8 AWG Wire
Create secure, moisture-resistant wire splices for outdoor lighting, irrigation systems and other wet-location electrical connections. The JW1050 combines a wide wire range with prefilled silicone sealant and a compact, installer-friendly body.
For distributors, OEM buyers, contractors and electrical-product sourcing teams.
Send your requirements, we will quote for you within 12 hours
Tel:+8613655777486
Why Choose the JW1050 Waterproof Wire Connector?
The JW1050 is designed to simplify outdoor splicing while protecting the connection from moisture. Its broad 22–8 AWG wire range helps reduce the number of connector sizes needed across common field applications.
Prefilled Silicone Sealant
Silicone sealant surrounds the splice and helps limit moisture entry during proper installation.
Wide Wire Compatibility
Supports selected solid or stranded conductor combinations from 22 AWG up to 8 AWG.
Secure Twist-On Connection
The fastening design grips conductors and helps the splice remain stable under normal vibration.
Outdoor Application Focus
For landscape lighting, irrigation controls and other outdoor connections exposed to moisture.
Compact Connector Body
The 38 × 27.2 × 24 mm body fits practical junction and enclosure layouts.
OEM and Bulk Supply
Ask TONFUL about packaging, labeling, wire-range selection and wholesale supply.
Technical Specifications
Use these values to screen the JW1050 for your application. Final selection should also consider conductor material, insulation, enclosure design and local electrical requirements.
| Model | JW1050 |
|---|---|
| Product type | Silicone-filled waterproof wire nut |
| Wire range | 22–8 AWG |
| Maximum voltage | 600 V; up to 1,000 V in fixtures and signs |
| Temperature rating | 105°C / 221°F |
| Sealant temperature range | -45°F to 400°F |
| Dimensions | 38 × 27.2 × 24 mm |
Selected 600 V Wire Combinations
Confirm the conductor type and exact combination before installation.
| Primary conductor combination | Additional conductor combination |
|---|---|
| 1–2 × 8 AWG | — |
| 1–5 × 12 AWG | — |
| 8 × 14 AWG | — |
| 1 × 10 AWG | 1–3 × 12 AWG |
| 1 × 10 AWG | 1–4 × 14 or 16 AWG |
| 2 × 10 AWG | 1–2 × 14 or 16 AWG |
| 3 × 12 AWG | 1 × 14 AWG |
| 3 × 12 AWG | 1–2 × 16 or 18 AWG |
| 2 × 14 AWG | 1–3 × 16, 18 or 20 AWG |
| 3–6 × 18 AWG | — |
| 1 × 12 AWG | 1–4 × 14, 16 or 18 AWG |
| 2–10 × 20 AWG | — |
Common Applications
Landscape Lighting
Outdoor luminaires, path lights and landscape-lighting branch connections.
Irrigation Systems
Sprinkler valves, controller wiring and moisture-exposed field connections.
Outdoor Fixtures
Signs, junction boxes and electrical fixtures requiring a sealed splice.
Direct-Burial Projects
Underground splices where the connector and complete installation meet project requirements.
Commercial Maintenance
Repair and replacement work across outdoor electrical systems and equipment.
OEM Product Assembly
Bulk supply for manufacturers using waterproof connectors in products or kits.
How to Install the JW1050
- Disconnect power. Verify the circuit is de-energized.
- Prepare the wires. Strip conductors and inspect for damage.
- Align the conductors. Match an approved wire combination.
- Twist clockwise. Tighten until conductors are firmly held.
- Inspect the splice. Confirm no bare conductor is exposed.
Selection Notes
Share these details with TONFUL:
- Conductor size and number of wires
- Solid or stranded conductor type
- System voltage and operating temperature
- Outdoor, buried, irrigation or fixture application
- Quantity, packaging and labeling
JW1050 Frequently Asked Questions
What wire sizes fit the JW1050 waterproof wire nut?
The stated range is 22–8 AWG. Select by the complete wire combination, not conductor size alone.
Can the JW1050 be used for landscape lighting?
Yes, when the wire combination, voltage and complete installation are suitable.
Is the connector prefilled with sealant?
Yes. The JW1050 is supplied with silicone sealant to help protect the splice from moisture.
What is the maximum voltage rating?
The stated maximum is 600 V, or up to 1,000 V in fixtures and signs under appropriate conditions.
Can TONFUL supply custom packaging or bulk orders?
Yes. TONFUL supports OEM, ODM and wholesale enquiries.
Need a Waterproof Wire Nut for Your Project?
Send TONFUL your wire sizes, application environment and order quantity. Our team will help evaluate the JW1050 and prepare a quotation.
